• Size: 95 mm x 58 mm x 11 mm (3.74” x 2.28” x 0.44”)
• Weight: 120 g (4.23 oz)
Dual chip architecture including:
- ST Micro STM32WB55 general purpose MCU with two embedded cores and a secure partition.
- M4F for the main applications and functions which require less security
- M0+ for the RF and security features. The M0+ is completely locked away to protect the RF Stack and the Infineon Optiga Trust-P secure element
- Display: 2.8” (71 mm) diagonal LCD, 320 × 240 pixel, capacitive touch screen
- Biometric sensor: 10 mm (0.39”) diameter Fingerprint sensor with proprietary matching algorithms
- Battery: 3.8V / 500mAh lithium-ion polymer, up to 6 hours of continuous use and several months in idle mode
- Carbon Key™ connectors: corrosion-resistant gold pogo pins
- Top enclosure: Precision zinc-allow case with bead-blasted finish
- Bottom enclosure: molded glass-fiber reinforced ABS with a rubberized texture applique
- Operating temperature: 0°C to +45°C (32°F to 113°F)
- Certifications: CC EAL5+, CE, RoHS, FCC
